| Type of Product | Reflector |
| Type | reflector |
| Suitable For | E3Z、E3ZM-C、E3ZM、E3Z-LT/LR/LL、E3S-C、E3G、E3JM/E3JK、E3S-CR62/67 |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Reflector |
Type |
reflector |
Suitable For |
E3Z、E3ZM-C、E3ZM、E3Z-LT/LR/LL、E3S-C、E3G、E3JM/E3JK、E3S-CR62/67 |
Country of Origin |
Japan |
Monotaro ID |
8585333 |
Material (reflector) |
(Reflection surface) Acrylic, (Back surface) ABS |
Positioning Angle |
30° or more |
Protection Class |
IEC standard IP67 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Manufacturer Part Number |
E39-R1 |
Storage Temperature Range |
-40 to 70℃ |
Storage Humidity Range |
35 to 95 %RH |
Operation Ambient Temperature (°C) |
-25 to 55 |
Operating Ambient Humidity |
35 to 85 %RH |
Detection Distance (mm) |
E3Z-R, E3ZM-CR, E3ZM-R (typical example): 3000 [100] (rated value), E3Z-LT / LR / LL (typical example): 15000 [300], E3S-C (Typical example): 3000 (rated value), E3G (typical example): 6000 [100] (rated value), E3JM-R4 @ 4 (T) (typical example): 4000 (rated value), E3JK- R2 @@ (representative example): 2500 (rated value), E3S-CR62 / 67: 1000 [250] |
Import Country |
Direct Import from Japan |
