| Type of Product | Residual Current Circuit Breaker with Over Current |
| Current Rating | 16A |
| Series | 5SV1316 |
| No. of Pole | 1P+N |
Type of Product |
Residual Current Circuit Breaker with Over Current |
Current Rating |
16A |
Series |
5SV1316 |
No. of Pole |
1P+N |
Range |
Sentron |
Country of Origin |
Romania |
Characteristic |
Type C |
Name of Manufacturer/Packer/Importer |
Siemens |
Circuit Type |
RCBO |
Mounting Style |
DIN Rail Mount |
Rated Voltage (AC) |
195V |
Break Time |
Instantaneous |
Better World Product |
Yes |
Overall Depth |
89.8mm |
Overall Dimensions |
17.6 x 70 x 89.8mm |
Overall Length |
17.6mm |
Breaking Capacity at Maximum Voltage Rating |
6 kA |
Overall Width |
70mm |
Pack of |
Each of 1 Piece |
Trip Sensitivity |
30mA |
Earth Leakage Protection Type |
A |
Manufacturer Model Number |
5SV1316-7KK16 |
Better World Claim |
Concentrated or compact solution, Extended product life, Low carbon manufacture |
Standards Met |
CE |
Terminal Contact Type |
Screw |
