Ships within 25 days
View
View
View
View
| Type of Product | Elbow LHSA (Left Thread) |
| Model No | LHSA8L |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | Nippon Thompson Co., Ltd. |
Type of Product |
Elbow LHSA (Left Thread) |
Model No |
LHSA8L |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Import Country |
Direct Import from Japan |
Monotaro ID |
10300297 |
Mass (g) |
64 g |
Dimension L (mm) |
48 |
Dimension L1 |
36 mm |
Dimension L2 |
19 mm |
Dimension D2 (mm) |
16 |
Dimension L3 (mm) |
12.5 |
Dimension D1 (mm) |
13 |
Remark |
Grease-filled product. |
Specifications |
1N≒0.102Kgf |
Dimension W1 (mm) |
14 |
Screw Direction |
Left-hand thread |
S (screw) |
M8×1.25 |
Dimension P |
10 mm |
Dimension V (mm) |
8 |
Dimensions D (mm) |
24 |
Dimensions A (mm) |
5 |
Dimension W2 (mm) |
14 |
