| Type | Absolute Rotary Encoder |
| Protection Structure | IP 64 |
| Ambient Humidity | 35 to 85%RH, storage: 35 to 90%RH |
| Connection | Cable Type (Cable Gland) |
Type |
Absolute Rotary Encoder |
Protection Structure |
IP 64 |
Ambient Humidity |
35 to 85%RH, storage: 35 to 90%RH |
Connection |
Cable Type (Cable Gland) |
Model No |
EP50S8-512-3F-P-24 |
Shaft Diameter |
8 mm |
Application |
Precision Machine tool, Fabric Machinery, Robot, Parking System |
Product Sub Type |
Shaft Type |
Overall Diameter |
50 mm |
Resolution |
512 P/R |
Rated Power Supply |
12-24 V |
Control Output |
PNP Open Collector Output |
Ambient Temperature |
-10 to 70°C, Storage: -25 to 85°C |
Warranty Duration |
12 Months Warranty As Per Autonics |
Revolution Direction |
Output value increase at CW Direction |
Output Code |
Gray Code |
Type of Product |
Rotary Encoder |
