| Protection Structure | IP50 |
| Model No | E40H8-600-6-L-24 |
| Resolution | 600P/R |
| Control Output | Line Driver |
Protection Structure |
IP50 |
Model No |
E40H8-600-6-L-24 |
Resolution |
600P/R |
Control Output |
Line Driver |
Output Phase |
A, , B, , Z, |
Weight |
Approx. 120g |
Accessories |
Bracket |
Type of Product |
Rotary Encoder |
Max Allowable Revolution |
5000 RPM |
Starting Torque |
Max. 50gf.cm(max. 0.0049N.m) |
Maximum Response Frequency |
300 kHz |
Environment Ambient Temperature |
-10 to 70℃, Storage: -25 to 85℃ |
Environment Ambient Humidity |
35 to 85% RH, Storage: 35 to 90% RH |
Connection Type |
Radial Cable Type |
Shaft Inner Diameter |
Ø8 mm |
Country of Origin |
South Korea |
Name of Manufacturer/Packer/Importer |
Teknocrats Control System (I) Pvt Ltd. |
Power Voltage |
12-24VDC ±5%(ripple P-P: max. 5%) |
