| Protection Structure | IP50 |
| Model No | E58SS6-2500-6-L-24 |
| Resolution | 2500P/R |
| Control Output | Line Driver |
Protection Structure |
IP50 |
Model No |
E58SS6-2500-6-L-24 |
Resolution |
2500P/R |
Control Output |
Line Driver |
Output Phase |
A, , B, , Z, |
Weight |
Approx. 395g(approx. 285g) |
Accessories |
Ø6mm coupling, Bracket |
Type of Product |
Rotary Encoder |
Max Allowable Revolution |
5000 RPM |
Starting Torque |
Max. 40gf.cm(max. 0.00392N.m) |
Maximum Response Frequency |
300 kHz |
Environment Ambient Temperature |
-10 to 70℃, Storage: -25 to 85℃ |
Environment Ambient Humidity |
35 to 85% RH, Storage: 35 to 90% RH |
Connection Type |
Axial Cable Type |
Shaft Outer Diameter |
Ø6 mm |
Country of Origin |
South Korea |
Name of Manufacturer/Packer/Importer |
Teknocrats Control System (I) Pvt Ltd. |
Power Voltage |
12-24VDC ±5%(ripple P-P: max. 5%) |
