| Protection Structure | IP54 (front part, IEC standard) |
| Connection | Terminal block |
| Model No | ENH-100-2-T-24 |
| Resolution | 100P/R |
Protection Structure |
IP54 (front part, IEC standard) |
Connection |
Terminal block |
Model No |
ENH-100-2-T-24 |
Resolution |
100P/R |
Control Output |
Totem pole |
Output Phase |
A, B |
Weight |
Approx. 330g(approx. 260g) |
Type of Product |
Rotary Encoder |
Max Allowable Revolution |
Normal: ≤ 200 rpm, Peak: ≤ 600 rpm |
Starting Torque |
Max. 1kgf.cm(max. 0.098N.m) |
Maximum Response Frequency |
10 kHz |
Environment Ambient Temperature |
-10 to 70℃, Storage: -25 to 85℃ |
Environment Ambient Humidity |
35 to 85% RH, Storage: 35 to 90% RH |
Country of Origin |
South Korea |
Name of Manufacturer/Packer/Importer |
Teknocrats Control System (I) Pvt Ltd. |
Power Voltage |
12-24VDC ±5%(ripple P-P: max. 5%) |
Click Stopper Position |
Normal L |
