| Type | Incremental Type |
| Model No | TRD-GK2500-BZ |
| Type of Product | Rotary Encoder |
| Number of Pulses | 2500 |
Type |
Incremental Type |
Model No |
TRD-GK2500-BZ |
Type of Product |
Rotary Encoder |
Number of Pulses |
2500 |
Maximum Response Frequency (kHz) |
100 |
Monotaro ID |
7487965 |
Import Country |
Direct Import from Japan |
Protection Class |
IP65 |
Series |
TRD-GK□-BZ Series |
Output Format |
Totem pole output |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
JTEKT Electronics (former Koyo Electronics Industries) |
Power Supply Voltage (V) |
DC 10 to 30 |
Output Signal Type |
Direction determination output/origin output (direct origin operation) |
Operation Ambient Temperature (°C) |
-10 to +70 |
Outer Diameter (Φmm) |
78 |
Allowable Rotation Speed (min-1 [rpm]) |
Maximum: 5000 |
Starting torque (N ・ m) |
0.1 or less |
Shaft Diameter (mm) |
Φ10 |
Acceptable Shaft Load (N) |
Radial Direction: 100 N/Thrust Direction: 50 N |
Control |
Rear cable (2m) |
Length (mm) |
60 |
