| Type | Rotary encoder |
| Model No | TRD-N120-RZB |
| Type of Product | Rotary Encoder |
| Number of Pulses | 120 |
Type |
Rotary encoder |
Model No |
TRD-N120-RZB |
Type of Product |
Rotary Encoder |
Number of Pulses |
120 |
Cable Length (m) |
0.5 (standard) |
Current Consumption (mA) |
60 or less (no load) |
Monotaro ID |
65112968 |
Mass (g) |
About 150 |
Import Country |
Direct Import from Japan |
Protection Class |
IP50 (dustproof) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
JTEKT Electronics (former Koyo Electronics Industries) |
Power Supply Voltage (V) |
DC 4.75 to 30 |
Classification |
Series: Shaft type |
Withstand Voltage |
For capacitor earth (between signal line and case) |
Maximum Rotation Speed (min⁻¹[rpm]) |
Acceptable: 5000 |
Signal |
Two-phase output type with origin (direct origin action) |
Insulation Resistance (MOhm) |
50 or more (between signal line and case) |
Outer Diameter (Φmm) |
50 |
Operation Mode |
Totem pole output |
Specifications |
Rear cable |
Load Voltage |
DC 35 V or less (power supply) |
Shaft Diameter (mm) |
Φ8 |
Length (mm) |
49 |
Output Voltage (V) |
H: ((power supply voltage)-2.5) or more, L: 0.4 or less |
Output Current (mA) |
Source H: Up to 10, Sink L: Up to 30 |
