| Type | For measuring |
| Model No | S-600-V |
| Output Phase | A, B phase |
| Type of Product | Rotary Encoder |
Type |
For measuring |
Model No |
S-600-V |
Output Phase |
A, B phase |
Type of Product |
Rotary Encoder |
Vibration Resistance |
30 minutes at 39.2m / s ² (4G) |
Number of Pulses |
600 |
Output phase difference |
90°±45° |
Current Consumption (mA) |
60 or less |
Monotaro ID |
38642396 |
Output Capacity |
Residual voltage 0.7V or less, sink current 30mA or less |
Mass (g) |
400 |
Import Country |
Direct Import from Japan |
Protection Class |
IP50 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
MUTOH HOLDINGS CO., LTD. |
Operating Temperature Range |
0 to 45℃ |
Storage Temperature Range |
-20 to 80℃ |
Inner Diameter (mm) |
(Axis) 23 (+ 0.15 / + 0.10) |
Allowable Rotation Speed (min-1 [rpm]) |
700 |
Operation Mode |
Voltage output, pull-up resistance 2kΩ |
Input Power |
DC 4.5 to 13 V |
Starting torque (N ・ m) |
50x10¯³ |
Cable |
Output / 2mΦ5.3 (with DIN8P connector) |
Specifications |
Moment of inertia: 255gcm ² |
Operating Humidity Range |
35 to 90% RH (no condensation) |
Shock Resistance (m/s²) |
(Durability) 490 (50G) |
