| Model No | NOC-HP2048-2MHT-10-050-00E |
| Type of Product | Rotary Encoder |
| Number of Pulses | 2048P/R |
| Maximum Response Frequency (kHz) | 200 |
Model No |
NOC-HP2048-2MHT-10-050-00E |
Type of Product |
Rotary Encoder |
Number of Pulses |
2048P/R |
Maximum Response Frequency (kHz) |
200 |
Current Consumption (mA) |
90 or less |
Monotaro ID |
11494625 |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NEMICON |
Power Supply Voltage (V) |
DC 10.8 to 26.4 |
Operation Mode |
High power supply voltage complementary output |
Shank Diameter (Φmm) |
10 |
Output Voltage (V) |
H: Power supply voltage -3 or more, L: 3 or less |
Maximum Current |
Maximum current draw: 40 mA |
Cable length (mm) |
500 |
Start-up Time |
Signal rise and fall time: 1 μs or less |
