| Model No | 18S-400-2MD-1-15-00E |
| Type of Product | Rotary Encoder |
| Starting Torque | 4.9 x 10-⁴ Nm or less |
| Vibration Resistance | 10 to 55 Hz/1.5 mm 2 hours each in X, Y and Z directions |
Model No |
18S-400-2MD-1-15-00E |
Type of Product |
Rotary Encoder |
Starting Torque |
4.9 x 10-⁴ Nm or less |
Vibration Resistance |
10 to 55 Hz/1.5 mm 2 hours each in X, Y and Z directions |
Cable Length |
15 cm |
Shock Resistance |
490 m/s² 11ms 3 times each in X, Y, Z directions |
Inertia Moment (kgm2) |
1x10⁵ |
Maximum Response Frequency (kHz) |
400P/R or less：120, 500P/R or more：240 |
Rise / Fall Time |
(Maximum) 100ns |
Ambient Humidity (% RH) |
85 or less (non-condensing) |
Monotaro ID |
52992233 |
Mass (g) |
20 or less |
Import Country |
Direct Import from Japan |
Protection Class |
IP50 |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NEMICON |
Power Supply Voltage (V) |
DC 4.5 to 5.5(Ripple 100mV(P-P) |
Maximum Rotation Speed (min⁻¹[rpm]) |
6000 |
Power Consumption |
(Maximum) 30 mA |
Operating Temperature Range |
-10 to 85℃ |
Storage Temperature Range |
-30 to 85℃ |
Operation Mode |
A ・ B ・ Z line driver |
Acceptable Shaft Load (N) |
Thrust direction: 4.9, Radial direction: 2.94 |
Output Voltage (V) |
H：2.5 or more, L：0.5 or less |
Pulse Measurement Range |
400 P/R |
