| Model No | E6C2-CWZ5B 360P/R 2M |
| Resolution | 360 P/R |
| Rated Power Supply | 12-24 V |
| Ambient Temperature | 10 to 70 ℃ |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
E6C2-CWZ5B 360P/R 2M |
Resolution |
360 P/R |
Rated Power Supply |
12-24 V |
Ambient Temperature |
10 to 70 ℃ |
Voltage |
12-24V DC |
Shaft |
Radial: 30 N Thrust: 20 N |
Type of Product |
Rotary Encoder |
Current Consumption |
80 mA max |
Insulation Resistance |
20 MΩ or higher |
Response Frequency (Hz) |
100 kHz |
Rotational Speed |
6000 RPM |
Vibration Resistance |
Destruction: 10 to 500 Hz |
Diameter |
50 mm |
Pulses |
360 |
Output Type |
Quadrature |
Dielectric Strength |
500 VAC 50/60 Hz 1 min |
Connection Method |
Cable |
Shock Resistance |
Destruction: 1000 m/s2 |
Sensor Type |
Incremental |
Mounting Type |
Panel Mount |
IP Rating |
IP64 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
