| Type | Rotary encoder |
| Ambient Humidity | During use and storage: 35 to 85% RH (no condensation) |
| Model No | E6C3-AG5C 720P/R 1M |
| Resolution | 720 pulses / revolution |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Rotary encoder |
Ambient Humidity |
During use and storage: 35 to 85% RH (no condensation) |
Model No |
E6C3-AG5C 720P/R 1M |
Resolution |
720 pulses / revolution |
Type of Product |
Rotary Encoder |
Output |
NPN open collector output |
Current Consumption |
70 mA or less When the power is turned on, an inrush current of about 6A flows. (Time: about 0.8ms) |
Insulation Resistance |
More than 20 MΩ (at 500 VDC) between live parts and case |
Cable Length |
1 mm |
Connection Type |
Cord drawer type |
Power Supply Voltage |
DC1210% 24 + 15% Ripple (pp) 5% or less |
Case Material |
Aluminum |
Rise / Fall Time |
1μs or less (Cord length 2m, sink current 30mA) |
Monotaro ID |
8587293 |
Output Capacity |
Applied voltage: DC30V or less Sink current: 35mA or less Residual voltage: 0.4V or less (when sink current is 35mA) |
Inertia Moment |
2.3×10⁶ kgm² |
Main Unit Material |
Aluminum |
Maximum Rotational Speed |
5000 min¹ [rpm] |
Protection Class |
IEC standard IP65, in-house standard oil-proof |
Direction of Rotation |
Output code increases in the CW direction (right rotation from the shaft side) when viewed from the shaft side |
Type of Output Code |
Gray binary |
Vibration Resistance (Destruction) |
10 to 500Hz Double amplitude 2 mm 150 m/s² X, Y, Z directions 3 times Sweep time 11min |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
