| Type | Rotary encoder |
| Model No | E6C3-AN1E-256P/R-1M |
| Resolution | 256 P/R |
| Control Output | Voltage output |
Type |
Rotary encoder |
Model No |
E6C3-AN1E-256P/R-1M |
Resolution |
256 P/R |
Control Output |
Voltage output |
Type of Product |
Rotary Encoder Absolute Type |
Connection Type |
Cord drawer type |
Power Supply Voltage |
DC 5±5% V |
Case Material |
Aluminum |
Cable Length (m) |
1 |
Current Consumption (mA) |
70 or less When the power is turned on, an inrush current of about 6A flows. (Time: about 0.8ms) |
Ambient Humidity (% RH) |
During operation and storage: 35 to 85 (but no condensation) |
Monotaro ID |
46432355 |
Output Capacity |
Output Resistance: 2.4Kω, Sink Current: 35 mA Or Less Residual Voltage: 0.4 V Or Less (At 35Ma Sink Current) |
Mass (g) |
Approx. 300 (packed) |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual Note: Couplings, fittings, and hexagonal spanners are sold separately. |
Main Unit Material |
Aluminum |
Protection Class |
IEC standard IP65 |
Direction of Rotation |
Switching by specifying the rotation direction |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Classification |
Absolute type shaft type |
Maximum Rotation Speed (min⁻¹[rpm]) |
5000 |
Operation Ambient Temperature (°C) |
During operation: -10 to 70, Storage: -25 to 85 (but do not freeze) |
Insulation Resistance (MOhm) |
Between live parts and case: 20 or more (at 500 V DC) |
Remark |
Confirm Delivery Date Each Time |
