| Type | Rotary encoder |
| Model No | E6C3-CWZ3XH-500P/R-1M |
| Resolution | 500 P/R |
| Type of Product | Rotary Encoder Incremental Type |
Type |
Rotary encoder |
Model No |
E6C3-CWZ3XH-500P/R-1M |
Resolution |
500 P/R |
Type of Product |
Rotary Encoder Incremental Type |
Output |
Line driver output |
Connection Type |
Pull-out cord type (cord length: 1m) |
Power Supply Voltage |
DC 5 to 12 V +10%, ripple (pp) 5% or less |
Case Material |
Aluminum |
Cable Length (m) |
1 |
Inertia Moment (kgm2) |
2.0x10¯⁶ |
Protection Circuit |
Output load short circuit protection |
Current Consumption (mA) |
When the power is turned on below 100, an inrush current of about 9A flows. (Time: about 0.1ms) |
Ambient Humidity (% RH) |
(Operating and storage) 35 to 85 (no condensation) |
Monotaro ID |
46439224 |
Output Capacity |
AM26LS31 equivalent output current, H level: IO = -10mA, L level: IS = 10mA, Output Voltage, VO=2.5V or more, VS=0.5V or less |
Mass (g) |
Approx. 300 (packed) |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual Note: Couplings, fittings, and hexagonal spanners are sold separately. |
Main Unit Material |
Aluminum |
Protection Class |
IEC60529 standard IP65 |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Classification |
Incremental shaft type |
Maximum Rotation Speed (min⁻¹[rpm]) |
5000 |
Insulation Resistance (MOhm) |
More than 20 (at 500 V DC) between live parts and case |
Remark |
Confirm Delivery Date Each Time |
