| Type | Rotary encoder |
| Model No | E6D-CWZ1E-720-P/R-0.5M |
| Resolution | 720 P/R |
| Control Output | Voltage output |
Type |
Rotary encoder |
Model No |
E6D-CWZ1E-720-P/R-0.5M |
Resolution |
720 P/R |
Control Output |
Voltage output |
Type of Product |
Rotary Encoder Incremental Type |
Connection Type |
Cord pull-out type (cord length: 0.5m) |
Power Supply Voltage |
DC 5 V ± 5% Ripple (pp) 5% or less |
Case Material |
Zinc alloy |
Cable Length (m) |
0.5 |
Inertia Moment (kgm2) |
3 x 10¯⁶ Or Less |
Rise / Fall Time |
1 μs or less |
Current Consumption (mA) |
150 or less |
Ambient Humidity (% RH) |
During use and storage: 35 to 85 (no condensation) |
Monotaro ID |
46440082 |
Output Capacity |
Output Resistance: 1Kω, Sink Current: 35 mA Or Less Residual Voltage: 0.7 V Or Less (At 10Ma Sink Current) |
Mass (g) |
Approx. 280 (packed) |
Import Country |
Direct Import from Japan |
Included Components |
Coupling type E69-C06B, Servo mount mounting bracket type E69-2, hexagonal wrench, instruction manual |
Main Unit Material |
Aluminum |
Protection Class |
IEC standard IP50 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Classification |
Shaft type |
Withstand Voltage |
Excluded due to capacitor earth. |
Maximum Rotation Speed (min⁻¹[rpm]) |
12000 |
Remark |
Confirm Delivery Date Each Time |
