| Type | Rotary encoder |
| Ambient Humidity | During use and storage: 35 to 85% RH (no condensation) |
| Model No | E6CP-AG5C-C 256 2M |
| Resolution | 256 pulses / revolution |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Rotary encoder |
Ambient Humidity |
During use and storage: 35 to 85% RH (no condensation) |
Model No |
E6CP-AG5C-C 256 2M |
Resolution |
256 pulses / revolution |
Weight |
Approx. 200 g (Packed) |
Type of Product |
Rotary Encoder |
Output |
Open collector output |
Current Consumption |
70 mA or less |
Insulation Resistance |
More than 20 MΩ (at 500 VDC) between live parts and case |
Cable Length |
2 mm |
Connection Type |
Connector |
Power Supply Voltage |
DC1210% 24 + 15% Ripple (pp) 5% or less |
Case Material |
ABS |
Monotaro ID |
39060183 |
Output Capacity |
Applied voltage: 28 VDC or less Sink current: 16 mA or less Residual voltage: 0.4 V or less (when sink current is 16 mA) |
Included Components |
Mounting bracket for servo mount |
Inertia Moment |
1 × 10⁶ kgm² or less |
Main Unit Material |
Polyphenylene sulfide |
Maximum Rotational Speed |
1000 min¹ [rpm] |
Protection Class |
IEC standard IP50 |
Direction of Rotation |
Output code increases with CW (right rotation as viewed from the shaft side) |
Type of Output Code |
Gray binary |
Accuracy |
± 1 ° or less |
Country of Origin |
CHINA |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
