Ships within 19 days
Model No
View
View
View
View
| Type | Incremental Type |
| Model No | E6C3-CWZ3EH-600P/R-2M |
| Resolution | 600 P/R |
| Type of Product | Rotary Encoder |
Type |
Incremental Type |
Model No |
E6C3-CWZ3EH-600P/R-2M |
Resolution |
600 P/R |
Type of Product |
Rotary Encoder |
Output |
Voltage Output (NPN Output) |
Connection Type |
Cord pull-out type (cord length: 2m) |
Power Supply Voltage |
DC 5-5% to 12+10% Ripple (pp) 5% or less |
Case Material |
Aluminum |
Cable Length (m) |
2 m |
Inertia Moment (kgm2) |
2.0x10¯⁶ |
Protection Circuit |
Output load short circuit protection |
Current Consumption (mA) |
When the power is turned on below 100, an inrush current of about 9A flows. (Time: about 0.1ms) |
Ambient Humidity (% RH) |
(Operating and storage) 35 to 85 (no condensation) |
Monotaro ID |
46438917 |
Output Capacity |
Output resistance: 2kΩ, Output current: 35 mA or less, Residual voltage: .7V or less |
Mass (g) |
Approx. 300 (packed) |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual Note: Couplings, fittings, and hexagonal spanners are sold separately. |
Main Unit Material |
Aluminum |
Protection Class |
IEC60529 standard IP65 |
Series |
E6C3-C Series |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Classification |
Incremental shaft type |
Maximum Rotation Speed (min⁻¹[rpm]) |
5000 |
Insulation Resistance (MOhm) |
More than 20 (at 500 V DC) between live parts and case |
Remark |
Confirm Delivery Date Each Time |
