Ships within 19 days
Model No
View
View
View
View
| Type | Incremental Type |
| Model No | E6C3-CWZ5GH 100P/R 1M |
| Resolution | 100 Pulses / Rotation |
| Type of Product | Rotary Encoder |
Type |
Incremental Type |
Model No |
E6C3-CWZ5GH 100P/R 1M |
Resolution |
100 Pulses / Rotation |
Type of Product |
Rotary Encoder |
Output |
Complementary Output |
Connection Type |
Cord Pull-Out Type (Cord Length 1 m) |
Power Supply Voltage |
DC 12-10% to 24+15% Ripple (pp) 5% or less |
Case Material |
Aluminum |
Cable Length (m) |
1 m |
Monotaro ID |
8587144 |
Mass (g) |
Approx. 300 (Packed) |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual Note: Couplings, metal fittings, and hexagon spanners are sold separately. |
Main Unit Material |
Aluminum |
Protection Class |
Iec60529 Standard IP65 (Jem Standard IP65F Drip-Proof/Oil-Proof) |
Series |
E6C3-C Series |
Material |
Shaft: Sus303 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Power Supply Voltage (V) |
DC 12-10% To 24+15% Ripple (Pp) 5% Or Less |
Maximum Rotation Speed |
5000 RPM |
Classification |
Incremental Form |
Withstand Voltage |
500 VAC 50/60 Hz For 1 min Between Current-Carrying Parts And Case |
