| Type | Rotary encoder |
| Model No | E6C3-AB5B-12P/R-2M |
| Resolution | 12P/R |
| Control Output | PNP open collector |
Type |
Rotary encoder |
Model No |
E6C3-AB5B-12P/R-2M |
Resolution |
12P/R |
Control Output |
PNP open collector |
Type of Product |
Rotary Encoder Absolute Type |
Connection Type |
Cord drawer type |
Power Supply Voltage |
DC 12 to 24 V + 15% Ripple (pp) 5% or less |
Case Material |
Aluminum |
Cable Length (m) |
2 |
Current Consumption (mA) |
70 or less When the power is turned on, an inrush current of about 6A flows. (Time: about 0.8ms) |
Ambient Humidity (% RH) |
During operation and storage: 35 to 85 (but no condensation) |
Monotaro ID |
46432154 |
Output Capacity |
Source current: 35 mA or less Residual voltage: 0.4V or less (at source current of 35mA) |
Mass (g) |
Approx. 300 (packed) |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual Note: Couplings, fittings, and hexagonal spanners are sold separately. |
Main Unit Material |
Aluminum |
Protection Class |
IEC standard IP65 |
Direction of Rotation |
Output code increases in the CW direction (right rotation from the shaft side) when viewed from the shaft side |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Classification |
Absolute type shaft type |
Maximum Rotation Speed (min⁻¹[rpm]) |
5000 |
Operation Ambient Temperature (°C) |
During operation: -10 to 70, Storage: -25 to 85 (but do not freeze) |
Insulation Resistance (MOhm) |
Between live parts and case: 20 or more (at 500 V DC) |
Remark |
Confirm Delivery Date Each Time |
