| Type of Product | Rotary Dip Switch |
| Monotaro ID | 39026793 |
| Color | (Rotor) white |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Rotary Dip Switch |
Monotaro ID |
39026793 |
Color |
(Rotor) white |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Output Code |
Real code |
Electrical Durability |
More than 5000 steps |
Withstand Voltage |
Between terminals: 250 VAC for 1 min |
Position |
10 |
Type |
Side operation Flat type |
Part No |
64-3336-39 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Manufacturer Part Number |
A6RV-101RF |
Operating Humidity Range |
35 to 95% RH (at +5 to + 35 ° C) |
Vibration Resistance (Malfunction) |
10-55Hz double amplitude 1.5mm |
Shock Resistance (Malfunction) |
300 or more |
Terminal Structure |
4x1 |
Contact Resistance (ohm) |
200 or less (initial value) |
Mass (g) |
About 0.8 |
Electrical ratings |
24V DC 25mA, 3.5V DC 10μA (minimum current) |
Operating Temperature Range |
-25 to +80℃ 60% RH or less |
Insulation Resistance (MOhm) |
100 or more (at 250 VDC) |
Operating Torque |
1.96x¹⁰⁻² N.m |
