| Type of Product | Slide Dip Switch |
| Monotaro ID | 39026906 |
| Color | (Strike) White |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Slide Dip Switch |
Monotaro ID |
39026906 |
Color |
(Strike) White |
Country of Origin |
Japan |
Contact Configuration |
1A (Normally Open Contact) |
Import Country |
Direct Import from Japan |
Operating Force (N) |
0.29 to 9.8 |
Electrical Durability |
1000 times or more |
Withstand Voltage |
Between terminals: AC500V 1min |
No. of Pole |
4-Pole |
Type |
Flat type (with seal tape) |
Part No |
64-3336-60 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Manufacturer Part Number |
A6S-4102-H |
Operating Humidity Range |
35 to 95% RH (at +5 to + 35 ° C) |
Vibration Resistance (Malfunction) |
10-55Hz double amplitude 1.5mm |
Shock Resistance (Malfunction) |
300 or more |
Contact Resistance (ohm) |
200 or less (initial value) |
Mass (g) |
0.41 |
Electrical ratings |
24 mA 25 mA, 3.5 V DC 10 μA (minimum current) |
Operating Temperature Range |
-20 to +70℃ 60% RH or less |
Insulation Resistance (MOhm) |
100 or more (at 250 VDC) |
Dimension A (Φmm) |
φ11.1 mm |
