| Protection Class | IP67(IEC60529) |
| Type of Product | Hs5D Safety Switch |
| Model No | HS5D-12RNM |
| Monotaro ID | 60054407 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IP67(IEC60529) |
Type of Product |
Hs5D Safety Switch |
Model No |
HS5D-12RNM |
Monotaro ID |
60054407 |
Contact Configuration |
1NO-2NC |
Conduit Size |
M20 |
Color |
Red (operation head color) |
Material |
Made of resin (head part) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Rated Impulse Withstand Voltage (kV) |
4 |
Electric Shock Protection Class |
ClassⅡ(IEC61140) |
Import Country |
Direct Import from Japan |
Insulation_Resistance (MΩ) |
Live metal part - non-charged metal part: 100 or more (at 500V DC megger) / Between different polarity live parts: 100 or more (at 500V DC megger) |
Mass (g) |
80 |
Impact Resistance (Durability) (m/s²) |
1000 |
Vibration Resistance |
Malfunction: 10 to 55Hz, single amplitude: 0.5mm/endurance: 30Hz, single amplitude: 1.5mm |
Body Color |
Black |
