| Protection Class | IP65(IEC 60529) |
| Type of Product | HE2B type enable switch |
| Model No | HE2B-M212PN1PN10 |
| Monotaro ID | 60049963 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IP65(IEC 60529) |
Type of Product |
HE2B type enable switch |
Model No |
HE2B-M212PN1PN10 |
Monotaro ID |
60049963 |
No. of Contacts |
2 contacts (3 position switch) 1 contact (return monitor switch) 2 contacts (push monitor switch) |
Contact Configuration |
3-Position Switch: 2 |
Type |
With Rubber Cover |
Color |
Gray (Rubber Cover) |
Material |
Nbr/Pvc Polyblend (Rubber Cover) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Rated Insulation Voltage (V) |
250 V |
Operating Force |
Direct opening: 60N or more (monitor switch) |
Import Country |
Direct Import from Japan |
Storage Temperature Range |
-40 To 80°C (No Icing) |
Insulation_Resistance (MΩ) |
Live parts and non-charged metal parts: 100 MΩ or more (at 500V DC megger) / Between different polarity live parts: 100 MΩ or more (at 500V DC megger) |
Specifications |
Reset Monitor Switch: 1 Contact, Push Monitor Switch: 2 Contacts, Terminal Soldering Conditions: 310-350°C, Within 3 Seconds, Operating Strength: 500N Or More (Full Button Press) |
Compatible Cable |
0.5 mm² or less (1 piece) |
Operation Ambient Temperature (°C) |
-10 To 60°C (No Icing) |
Mass (g) |
26 |
Relative Humidity |
45% to 85% (with no condensation) |
Applicable Standard |
IEC/EN60947-5-8 (TUV certified), IEC/EN60947-5-1, JISC8201-5-1, UL508 (UL recognition certified), CSAC22.2No.14 (c-UL recognition certified), GB/T14048.5 (CCC certified), Application standards: ISO12100/ENISO12100, IEC60204-1/EN60204-1, ISO11161/ENISO11161, ISO10218-1/ENISO10218-1, ANSI/RIAISO10218-1, ANSI/RIA/R15.06, ANSIB11.19, ISO13849-1/ENISO13849-1 |
Terminal Shape |
Solder Terminal |
Vibration Resistance (Destruction) |
16.7 Hz, Single Amplitude 1.5 mm |
Rated Operating Current (A) |
[3-position switch] Resistive load (AC-12)/Inductive load (AC-15): 1/0.7 (AC125V), 0.5 (AC250), Resistive load (DC-12)/Inductive load (DC-13): 1/0.7A (DC30V), 0.2/0.1 (DC125V), [Return monitor switch/push monitor switch (NC contact)] Resistive load (AC-12)/Inductive load (AC-15): 2.5/1.5 (AC125V), 1.5/0.75 (AC250V), Resistive load (DC-12)/Inductive load (DC-13): 2.5/2.3 (DC30V), 1.1/0.55 (DC125V), 0.55/0.27 (DC250V) |
