IDEC HS1T type safety switch with solenoid 4 Contact Type 250 V (LED, solenoid-ground: 3V), HS1T-VA44ZM-G

Name: IDEC HS1T type safety switch with solenoid 4 Contact Type 250 V (LED, solenoid-ground: 3V), HS1T-VA44ZM-G
Brand: IDEC
SKU: IND.SAF.937702915
Price: 21239 INR
Availability: InStock

Visit the IDEC Store

EMI starts at ₹1887/month. No Cost EMI available.

Available offers

Flat ₹300 off on Order above ₹7,000 | Valid for NEW Business Users

View

Flat ₹200 off on Order above ₹5000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Features

Protection Class	IP67(IEC60529)Type 4X Indoor Use Only
Type of Product	HS1T type safety switch with solenoid
Model No	HS1T-VA44ZM-G
Monotaro ID	47999825

More IDEC Safety Switch products More Safety Switch products

Warranty as per brand

100% Original Products

Secure payments

100% Buyer protection

Top Brands

specifications

Protection Class	IP67(IEC60529)Type 4X Indoor Use Only
Type of Product	HS1T type safety switch with solenoid
Model No	HS1T-VA44ZM-G
Monotaro ID	47999825
Contact Configuration	Door Monitor Circuit: 1Nc, 1No / Lock Monitor Circuit: 1Nc, 1No
Type	4 Contact Type
Country of Origin	Japan
Name of Manufacturer/Packer/Importer	IDEC Corporation
Rated Insulation Voltage (V)	250 V (LED, solenoid-ground: 3V)
Vibration Resistance (Malfunction)	10 To 55 Hz, Single Amplitude: 0.35 mm Or More
Mechanical Durability	2 million times or more
Electrical Durability	100,000 times or more (AC-15 250V/0.75A), 2 million times or more (AC/DC 24V 100mA) (operation frequency 900 times/hour)
Electric Shock Protection Class	Class II(IEC61140)
Operating Force	Direct open circuit: 120N
Import Country	Direct Import from Japan
Storage Temperature Range	-40 To 80°C (No Icing)
Insulation_Resistance (MΩ)	Charging metal part-non-charging metal part: 100 MΩ or more (at DC500V megger), between opposite terminals: 100 MΩ or more (at DC500V megger)
Specifications	Type And Coding Level: Type 2 Interlocking Device Low Level Coded (En Iso 14119), Actuator Operating Speed: 0.05 To 1 M/S
Operation Ambient Temperature (°C)	-25 To 55°C (No Icing)
Mass (g)	About 450
Relative Humidity	20 to 95% RH (no condensation)
Tensile Strength (N)	Actuator when locked: Fzh=5000 or more (GS-ET-19)
Applicable Standard	EN ISO / ISO14119, IEC60947-5-1, EN60947-5-1 (TUV certified), GS-ET-19 (TUV certified), UL508 (UL Listed), CSA C22.2 No.14 (c-UL Listed), GB/T 14048.5 (CCC certified), Application standards: IEC60204-1/EN60204-1
Vibration Resistance (Destruction)	30 Hz, Single Amplitude: 1.5 mm Or More
Cable	One stranded or solid wire of 0.3 <sup>mm2</sup> to 1.5 <sup>mm2</sup> or AWG22 to AWG16
Conditional Short-Circuit Current	50A(250V)
