| Protection Class | IP67(EN60947-5-1) |
| Type of Product | Safety Door Switch with Small Electromagnetic Lock |
| Model No | D4NL-4EFG-B4 |
| Monotaro ID | 46535115 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IP67(EN60947-5-1) |
Type of Product |
Safety Door Switch with Small Electromagnetic Lock |
Model No |
D4NL-4EFG-B4 |
Monotaro ID |
46535115 |
Type |
Standard Type |
Head Material |
Plastic |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operating Force (N) |
(Direct Opening) Minimum 60N (EN60947-5-1) |
Insulation Resistance |
100 or more (with 500 V DC mega) |
Contact Resistance |
25 or Less (Per Contact) |
Shock Resistance |
1000 m/s² or More |
Operation Ambient Temperature |
-10 to 55 (No Icing) |
Rated Frequency (Hz) |
50/60 Hz |
Rated Insulation Voltage (V) |
(Ui)300(EN60947-5-1) |
Ambient Humidity to Use |
95% RH or Less |
Mounting Side |
Can be Installed in 4 Directions (Front Facing When Shipped) |
Vibration Resistance (Malfunction) |
10-55 Hz 0.75 mm Single Amplitude |
Shock Resistance (Malfunction) |
Over 100 m/s square or More |
Mechanical Durability |
1,000,000 Times or More |
Rated Impulse Withstand Voltage (kV) |
Between Same Pole Terminals: 2.5 Between Different Pole Terminals: 4 Between Each Terminal and Non-Charged Metal Part: 6 |
Allowable Operating Speed |
0.05~0.5 m/s |
Electrical Durability |
500,000 Times or More (250 V AC 3 A, with Resistive Load) |
Electric Shock Protection Class |
Class II (Double Insulation) |
Minimum Applicable Load |
5 V DC 1 mA Resistance Load (N Level Reference Value) |
