| Protection Class | IP67(EN60947-5-1) |
| Type of Product | Safety Door Switch with Small Electromagnetic Lock |
| Model No | D4NL-2GFG-B4 |
| Monotaro ID | 46534521 |
Protection Class |
IP67(EN60947-5-1) |
Type of Product |
Safety Door Switch with Small Electromagnetic Lock |
Model No |
D4NL-2GFG-B4 |
Monotaro ID |
46534521 |
Conduit Size |
G1/2 |
Indicator Lamp |
AC / DC 10 to 115 V drive type (orange LED display) |
Type |
Standard type |
Pollution degree |
Pollution degree 3 (EN60947-5-1) |
Head Material |
plastic |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Shock Resistance |
1000m / s <sup>2</sup> or more |
Rated Frequency (Hz) |
50/60 |
Rated Insulation Voltage (V) |
(Ui)300(EN60947-5-1) |
Mounting Side |
Can be installed in 4 directions (front facing when shipped) |
Vibration Resistance (Malfunction) |
10-55Hz 0.75mm single amplitude |
Mechanical Durability |
1,000,000 times or more |
Rated Impulse Withstand Voltage (kV) |
Between terminals of the same polarity: 2.5, Between terminals of different polarities: 4, Between each terminal and non-current-carrying metal parts: 6 |
Allowable Operating Speed |
0.05～0.5m/s |
Electrical Durability |
500,000 times or more (AC250V 3A, with resistive load) |
Electric Shock Protection Class |
Class II (double insulation) |
Minimum Applicable Load |
DC5V 1mA resistance load (N level reference value) |
Operating Force |
(Direct opening) Minimum 60N (EN60947-5-1) |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-10 to 55 (no icing) |
Door Lock Type |
DC24V solenoid lock |
Insulation Resistance (MOhm) |
100 or more (with DC500V mega) |
Operating Ambient Humidity (% RH) |
95 or less |
Shock Resistance (Malfunction) (m/s²) |
over 100 |
Contact Resistance (m ohm) |
25 or less (per contact) |
Conditional Short Circuit Current (A) |
100(EN60947-5-1) |
Vibration (Malfunction) Hz |
10 to 55 Single amplitude 0.75 mm |
In-built Switch |
3NC (slow action) + 1NC / 1NO (slow action) |
Pull-out Strength (N) |
When locked: Minimum 1300 |
Release method |
Mechanical release type |
Position |
(Release key position) Bottom |
Allowable Operation Frequency (Times / Min) |
Up to 30 |
Release Key |
Special release key (resin) (Note: Release tool is shipped attached to the main unit) |
Open thermal current (A) |
10(EN60947-5-1) |
Shock Resistance (m/s²) |
1000 or more |
Pretravel (PT) |
Up to 9mm |
