| Operation Ambient Temperature | -10 to 55℃ (no freezing or condensation) |
| Short Circuit Protection Device | gG 2A (IEC60269 fuse) |
| Insulation Resistance | 100 mΩ or more (at 500 VDC megger) |
| Rated Impulse Withstand Voltage (kV) | 2.5 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Operation Ambient Temperature |
-10 to 55℃ (no freezing or condensation) |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Insulation Resistance |
100 mΩ or more (at 500 VDC megger) |
Rated Impulse Withstand Voltage (kV) |
2.5 |
Return Function |
Automatic (middle ← right) |
Contact Configuration |
2C |
Withstand Voltage |
Between charging part and ground: AC 2000 V 1 minute, between opposite pole charging part: AC 2000 V 1 minute |
Mechanical Durability |
250,000 times or more |
Protection Class |
Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof) JIS C 0920 / IP2X (fast-connecting socket AR6S690, for connectors) When socket AR6S691-C or charging part protective cover AR6Y261 is installed) |
Pollution Degree (Environment to Use) |
3 |
Monotaro ID |
49998934 |
Storage Temperature |
-40 to 70℃ |
Rated Insulation Voltage (V) |
AC/DC 250 |
Type of Product |
Selector Switch |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Mounting Hole Diameter (Φmm) |
16 |
Type |
Right-Angle Key Type |
Notch Angle |
45° |
Model No |
AF16JT-7AC2F |
Terminal Shape |
For solder and tab (# 110) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Number of Notches |
3 |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
