| Operation Ambient Temperature | -10 to 55℃ (no freezing or condensation) |
| Insulation Resistance | 100 mΩ or more (at 500 VDC megger) |
| Return Function | Manual |
| Contact Configuration | 2C |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Operation Ambient Temperature |
-10 to 55℃ (no freezing or condensation) |
Insulation Resistance |
100 mΩ or more (at 500 VDC megger) |
Return Function |
Manual |
Contact Configuration |
2C |
Withstand Voltage |
Between live part and ground / between different polarity live parts: 2000 V AC for 1 minute |
Mechanical Durability |
250,000 times or more |
Protection Class |
Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof type) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof type) JIS C 0920 / terminal protection structure: IP2X (for quick connection) When socket AR6S690, connector socket AR6S691-C or charging part protection cover AR6Y261 is installed) |
Monotaro ID |
50038694 |
Storage Temperature |
-40 to 70℃ |
Rated Insulation Voltage (V) |
AC/DC 250 |
Type of Product |
Selector Switch |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Mounting Hole Diameter (Φmm) |
16.2 |
Type |
Round Knob Type |
Notch Angle |
45° |
Rated Operating Current (A) |
AC-13 (coil load): 1 (110 V) / 1 (120 V) / 0.7 (220 V), AC-12 (resistive load): 1.5 (110 V) / 1.5 (120 V) / 1 (220 V), DC-13 (coil load): 0.7 (24 V) / 0.15 (110 V) / 0.15 (125 V), DC-12 (resistive load): 1 (24 V) / 0.2 (110 V) / 0.2 (125 V) |
Model No |
AR16JR-3BC2A |
Terminal Shape |
For solder and tab (# 110) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Number of Notches |
3 |
Standard |
UL, CSA, EN standards (TUV), CE, CCC |
Mass (g) |
22.5 |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Outer Diameter (Φmm) |
18 |
