| Terminal Screw | M3.5 plus/minus screw with square washer (self-lifting type) |
| Short Circuit Protection Device | Fuse 15A |
| Rated Impulse Withstand Voltage (kV) | 6 |
| Return Function | Manual |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Short Circuit Protection Device |
Fuse 15A |
Rated Impulse Withstand Voltage (kV) |
6 |
Return Function |
Manual |
Contact Configuration |
3A |
Withstand Voltage |
Between live part and ground / between different polarity live parts: 2500 VAC for 1 minute |
Mechanical Durability |
1,000,000 times or more |
Protection Class |
Operation section: IP65 (oil-proof type) |
Pollution Degree (Environment to Use) |
3 |
Monotaro ID |
50066177 |
Frame |
Round frame |
Storage Temperature |
-40 to 80℃ |
Rated Insulation Voltage (V) |
AC/DC 600 |
Type of Product |
Selector Switch |
Electrical Durability |
500,000 times or more (at AC220V 6A), 1 million times or more (at AC220V 3A) |
Mounting Hole Diameter (Φmm) |
30 |
Type |
Standard Type |
Notch Angle |
90° |
Model No |
AR30PR-230R |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Number of Notches |
2 |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20 to 70 (no freezing or condensation) |
Insulation Resistance (MOhm) |
Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
