| Contact Configuration | 2a |
| Withstand Voltage | Between live part and ground / (Contact part) AC2500V for 1 minute, (Lighting part) AC2500V for 1 minute |
| Mechanical Durability | 1 million times |
| Relative Humidity | 45 to 85% |
Contact Configuration |
2a |
Withstand Voltage |
Between live part and ground / (Contact part) AC2500V for 1 minute, (Lighting part) AC2500V for 1 minute |
Mechanical Durability |
1 million times |
Relative Humidity |
45 to 85% |
Protection Class |
IP65 oil-proof type |
Monotaro ID |
37845534 |
Rated Insulation Voltage (V) |
AC/DC 600 |
Type of Product |
Illuminated Selector Switch |
Mounting Hole Diameter (Φmm) |
25.5(+0.5 to 0) |
Type |
With transformer |
Rated Operating Current (A) |
Contact part (110V): AC-15 class (inductive load) / 6, DC-13 class (inductive load) /0.7, DC-12 class (resistive load) / 2 |
Operation Type |
2 notch manual reset |
Shape |
Knob type 2 notch (metal ring) |
Model No |
A25FST210020GLE |
Light Source |
LED sphere (High Bright Economy) |
Voltage |
100/110 V |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Number of Notches |
2 |
Name of Manufacturer/Packer/Importer |
Maruyasu Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20 to 55 |
Contact Resistance (ohm) |
30 mΩ or less |
Insulation Resistance (MOhm) |
100 mohm or more (500 V) |
Cold Resistance |
-40 to 70℃ |
Temperature Rise |
40K or less |
Heat Resistant Temperature (℃) |
-40 to 70 |
Rated Secondary Voltage (V) |
(Illumination section) 5.5 |
