| Contact Configuration | 2a |
| Withstand Voltage | Between live part and ground / AC2200V for 1 minute |
| Mechanical Durability | 1 million times |
| Relative Humidity | 45 to 85% |
Contact Configuration |
2a |
Withstand Voltage |
Between live part and ground / AC2200V for 1 minute |
Mechanical Durability |
1 million times |
Relative Humidity |
45 to 85% |
Protection Class |
IP65 oil-proof type |
Monotaro ID |
37855456 |
Rated Insulation Voltage (V) |
AC/DC 600 |
Type of Product |
Selector Switch |
Electrical Durability |
1 million times |
Mounting Hole Diameter (Φmm) |
30.5(+0.5 to 0) |
Notch Angle |
45° |
Rated Operating Current (A) |
AC-15 class (inductive load): 24V/10, 48V/10, 110V/6, 220V/4, 440V/1.5, DC-13 class (inductive load): 24 V/6, 48V/2, 110V/0.7, 220V/0.3, DC-12 class (resistive load): 24V/6, 48V/3, 110V/2, 220V/1 |
Operation Type |
Right automatic return |
Shape |
Knob shape (metal ring) |
Color |
(Knob part) Black |
Model No |
A30SN3R11B |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Number of Notches |
3 |
Name of Manufacturer/Packer/Importer |
Maruyasu Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20 to 55 |
Contact Resistance (ohm) |
30 mΩ or less |
Insulation Resistance (MOhm) |
100 mohm or more (500 V) |
Cold Resistance |
-40 to 70℃ |
Temperature Rise |
40K or less |
Heat Resistant Temperature (℃) |
-40 to 70 |
Mounting Side |
Contact unit / Horizontal mounting (Terminal direction / Left / Right) |
