| Contact Configuration | 2B+1A |
| Mechanical Durability | 100,000 times or more |
| Protection Class | IP65 (from front of panel) |
| Pollution Degree (Environment to Use) | 3(EN60947-5-1) |
Contact Configuration |
2B+1A |
Mechanical Durability |
100,000 times or more |
Protection Class |
IP65 (from front of panel) |
Pollution Degree (Environment to Use) |
3(EN60947-5-1) |
Monotaro ID |
66358093 |
Storage Temperature |
-40 to 70 ℃ |
Type of Product |
Safety Key Selector Switch |
Electrical Durability |
100,000 times or more |
Mounting Hole Diameter (Φmm) |
22 |
Type |
Safety Key Selector Switch |
Model No |
A22TK-2LR-12-01-SJ |
Electric Shock Protection Class |
Class Ⅱ |
PTI (Proof Tracking Index) |
175 |
Country of Origin |
JAPAN |
Terminal Type |
Screw terminal (M3.5) |
Import Country |
Direct Import from Japan |
Number of Notches |
2 |
Key Type |
Type with key removal prevention function |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-20 to 70 (no freezing or condensation) |
Insulation Resistance (MOhm) |
100 or more (with DC 500 V mega) |
Safety Standard |
UL, cUL(File No.E41515)/TUV(EN60947-5-1)(Low Voltage Directive)/CCC(GB/T 14048.5) |
Key insertion / removal position |
Left |
Specifications |
Confirm delivery date each time |
