Ships within 25 days
View
View
View
View
| Material | High Carbon Steel |
| Type of Product | Self-Aligning Ball Bearings 2300 Series Taper Hole |
| Model No | 2304SK |
| Load direction | Radial |
Material |
High Carbon Steel |
Type of Product |
Self-Aligning Ball Bearings 2300 Series Taper Hole |
Model No |
2304SK |
Load direction |
Radial |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Self-Aligning Ball Bearings |
Rolling element material |
High Carbon Chromium Bearing Steel |
JIS grade |
0 |
Width B (mm) |
21 |
Monotaro ID |
344215 |
Shaft Hole Type |
Tapered hole type |
Outer Diameter D (Φmm) |
52 |
Reference mass (g) |
207 |
Basic static load rating Cor (N) |
4700 |
Basic dynamic load rating Cr (N) |
18500 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Chamfer Dimension r (mm) |
1.1 (minimum) |
Inner Diameter (mm) |
20 |
Permissible Speed (min-1) Grease Lubrication |
11000 |
Permissible Speed (min-1) Oil Lubrication |
14000 |
