| Type of Product | Fiber Unit Reflective Type |
| Series | E32 Series |
| Model No | E32-C11N 2M |
| Type | Special Beam Type |
Type of Product |
Fiber Unit Reflective Type |
Series |
E32 Series |
Model No |
E32-C11N 2M |
Type |
Special Beam Type |
Monotaro ID |
39047976 |
Operation Ambient Temperature |
-40～+70℃ |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Ambient Humidity |
35～85%RH |
Protection Class |
IEC standard IP67 |
Material (Detection Surface) |
Brass Nickel Plating |
Detection Distance |
High Precision Mode: 280 mm, Standard Mode: 170 mm, Fast Mode: 160 mm, Fastest Mode: 50 mm (When Using Amplifier Unit Type E3X-DA-S [General Purpose Type]) |
Detection Method |
Reflective Type |
Head Shape |
Screw |
Bending Radius |
4 mm |
Minimum Detectable Object |
This is the value when the detection distance and sensitivity are set to the optimum state in Φ0.005 mm standard mode. |
Tensile Strength |
29.4N |
Fiber Length (mm) |
2000 mm |
Material (Fiber) |
Plastic (Vinyl Chloride Coating and Polyethylene) |
Tightening Torque |
0.98 Nm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
