Ships within 30 days
Model No
View
View
View
View
| Type of Product | Fiber Unit Reflective Type |
| Series | E32 Series |
| Model No | E32-D61-S 2M |
| Type | Environmental/Heat Resistant |
Type of Product |
Fiber Unit Reflective Type |
Series |
E32 Series |
Model No |
E32-D61-S 2M |
Type |
Environmental/Heat Resistant |
Monotaro ID |
39048283 |
Operation Ambient Temperature |
-60～+350℃ |
Country of Origin |
Japan |
Ambient Humidity |
35～85%RH |
Protection Class |
IEC standard IP67 |
Material (Detection Surface) |
Stainless Steel (SUS303) |
Detection Distance |
High Precision Mode: 150 mm, Standard Mode: 90 mm, Fast Mode: 60 mm, Fastest Mode: 27 mm (When Using Amplifier Unit Type E3X-DA-S [General Purpose Type]) |
Detection Method |
Reflective Type |
Head Shape |
Screw |
Bending Radius |
25 mm |
Minimum Detectable Object |
This is the value when the detection distance and sensitivity are set to the optimum state in Φ0.005 mm standard mode. |
Tensile Strength |
29.4N |
Fiber Length (mm) |
2000 mm |
Material (Fiber) |
Glass (SUS Spiral Coating) |
Tightening Torque |
0.98 Nm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
