| Weight | About 140 g |
| Type of Product | Sensor Controller |
| Power Supply Voltage | DC24±10% |
| Model No | S3D2-AKD |
Weight |
About 140 g |
Type of Product |
Sensor Controller |
Power Supply Voltage |
DC24±10% |
Model No |
S3D2-AKD |
Type |
2 input 1 output single function (AND / OR operation) type |
Monotaro ID |
39095332 |
Power Consumption |
2.5 VA or less (excluding sensor power supply) |
Mechanical Life |
(Relay output) 50 million times or more (opening and closing frequency 18000 times / hour) |
Power for Sensor |
DC24V (supplied from power supply voltage) |
Timer Function |
None |
Electrical Life (Rated Load) |
(Relay output) 100,000 times or more (opening / closing frequency 1800 times / hour) |
Input Signal |
ON：0～4V(5mA以上) OFF：8～30V(2mA以下) 短絡電流：11mA TYP(18mA max.) 最大印加電圧：30V |
Control Output |
Relay output 1c (common), AC250V 3A (cosΦ = 1) |
Response Time |
(Input) 0.1 ms, (Output) 10 ms or less |
Minimum pulse width |
(Output) 10 ms or less |
Noise Resistance |
Power supply for operation: 480Vpp or more, pulse width 100ns, 1μs, pulse with a rising edge of 1ns, Input/output: 1000Vpp or more, pulse width 100ns, 1μs, pulse with rising edge 1ns |
Other functions |
Signal input inversion function, AND / OR operation mode switching function |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Ambient Temperature |
Operating: 10 to +55℃, Storage: 25 to +65 ℃ (with no icing) |
Ambient Humidity |
During operation and storage: 35 to 85% RH each |
Withstand Voltage |
AC1500 or more Between all power terminals and uncharged metal parts |
Vibration Resistance (Destruction) |
10 to 55Hz, double amplitude 0.75mm X, Y, Z directions 2h |
Power Outage Compensation Time |
(Instantaneous) 20 ms or less |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
