| Type of Product | Signal Relay |
| Height | 6.9 mm |
| Country of Origin | Slovenia |
| Mounting Type | PCB Mount |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Signal Relay |
Height |
6.9 mm |
Country of Origin |
Slovenia |
Mounting Type |
PCB Mount |
Length |
13 mm |
Series |
P1 |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Coil Voltage |
24 V DC |
No. of Pole |
1 |
Maximum Switching Voltage (AC) |
125 V AC |
Switching Current |
2 A |
Contact Configuration |
SPDT |
Manufacturer Part Number |
30.22.7.024.0010 |
Minimum Operating Temperature |
-40°C |
Coil Resistance |
3100 Ω |
Depth |
7.6 mm |
Latching |
No |
Maximum Operating Temperature |
+85°C |
Terminal Type |
Through Hole |
Coil Power Consumption |
200 mW |
Operating Cycle |
10000000 (Electrical) Cycles, 10000000 (Mechanical) Cycles |
Maximum Switching Power AC |
125VA |
Isolation Coil To Contact |
1.5 kV AC |
Maximum Switching Power DC |
125 W |
