| Model No | ST4-A1-J02 |
| Type of Product | Compact Safety Beam Sensor |
| Material | Case: PBT (Polybutylene terephthalate), Lens: Acrylic, Display cover: Acrylic |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
ST4-A1-J02 |
Type of Product |
Compact Safety Beam Sensor |
Material |
Case: PBT (Polybutylene terephthalate), Lens: Acrylic, Display cover: Acrylic |
Country of Origin |
Japan |
Cable |
With shielded cable with connector 0.2m |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
73954703 |
Current Consumption (mA) |
Emitter: 11 or less, Receiver: 9 or less |
Applicable Standard |
IEC 61496-1 / 2 (JIS B 9704-1 / 2 / UL 61496-1 / 2) (Type 4), ISO 13849-1 (Category 4, PLe), JIS B 9705-1 (Category 4), IEC 61508 -1 to 7 (SIL3), IEC 62061 (SIL3), JIS C 0508-1 to 7 (SIL3), UL 1998, OSHA 1910.212, OSHA 1910.217 (C), ANSI B11.1 to B11.19, ANSI / RIA R15 .06, ANSI / ISA S84.01 (SIL3) |
Import Country |
Direct Import from Japan |
Power Supply Voltage |
Supplied from the controller |
Detection Distance (m) |
0.1 to 15 |
Protection Class |
IP67 (IEC) |
Ambient Humidity to Use |
30-85% RH, Storage: 30-95% RH |
Operation Ambient Temperature (°C) |
-10 to +55 (with no condensation or icing), storage: -25 to +70 |
Mass (g) |
About 45 |
Emitting Element |
Infrared LED (Peak emission wavelength: 870nm) |
Opening Angle |
± 2.5° or less when detection distance exceeds 3m (according to IEC 61496-2 / UL 61496-2) |
Withstand voltage (V) |
AC 1000 for 1 minute between charged parts and case |
Insulation Resistance |
20 MΩ min. At 500 V DC megger between charged parts and case |
Ambient Illumination to Use (Lx) |
Incandescent lamp: Light-receiving surface illuminance of 3500 or less |
Vibration Resistance |
Durability 10 to 55 Hz, double amplitude 0.75 mm or maximum acceleration 90m/s2 2 hours in each direction of XYZ |
Objects to Detect |
Opaque body with a diameter of 9 mm or more |
Indicator Lamp |
Shading: Red LED (lights up when light is blocked / locked out, lights off when light is received), Emitter: Green LED (lights up when light is emitted, lights off when light is stopped), Stable light: Green LED (lights up when light is stable, (Turns off when unstable light is received) |
Extension Distance |
Can be extended up to 50m in total length of light emitter / receiver with special cable sold separately |
Shock Resistance |
Durability 300m/s2 XYZ each direction 3 times |
