Panasonic Air Flow Monitor 500 ms Response Time, AEWA2040

Name: Panasonic Air Flow Monitor 500 ms Response Time, AEWA2040
Brand: Panasonic
SKU: AUT.SEN.537826345
Price: 141599 INR
Availability: InStock

Visit the Panasonic Store

EMI starts at ₹12581/month. No Cost EMI available.

Available offers

Flat ₹300 off on Order above ₹7,000 | Valid for NEW Business Users

View

Flat ₹200 off on Order above ₹5000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Features

Model No	AEWA2040
Type of Product	Air Flow Monitor
Material	Gas contact parts: Aluminum alloy, PPS, fluorosilicone rubber
Country of Origin	Japan

More Panasonic Sensor & Relay products More Sensor & Relay products

Warranty as per brand

100% Original Products

Secure payments

100% Buyer protection

Top Brands

specifications

Model No	AEWA2040
Type of Product	Air Flow Monitor
Material	Gas contact parts: Aluminum alloy, PPS, fluorosilicone rubber
Country of Origin	Japan
Type	Medium caliber
Included Components	Centering collar: 4 pieces, M4 hexagon wrench: 1 piece, Flange packing: 2 pieces, Bolt set (bolt, nut, plain washer): 1 set
Name of Manufacturer/Packer/Importer	Panasonic Corporation
Monotaro ID	73885498
Response Time	500 ms
Import Country	Direct Import from Japan
Protection Class	IP64(IEC)
Ambient Humidity to Use	90% RH or less, but no condensation or icing
Operation Ambient Temperature (°C)	-10 to +60 (when stored: -20 to +70)
Standard	CE
Rated Pressure Range	0 to less than 1 Mpa (gauge pressure)
Output Mode	Pulse output / positive flow pulse, analog current output / instantaneous flow rate, pressure, temperature (selectable in setting mode)
Mass (Kg)	About 1.0
Pressure loss	Minimal (equivalent to straight pipe)
Flow Range	-9.4 to -580N or +9.4 to + 580N m³ (normal flow rate) Supply pressure 0.7 MPa When the pipe temperature is 25°C
Pulse Output	Open drain output, Maximum inflow current: 50 mA, Applied voltage: 24 V DC or less, Residual voltage: 1.5 V or less (at inflow current of 50 mA)
Diameter	40 A
Output Time	Duty (1: 1) 50/100/125/250 / 500ms (Select in setting mode)
Overcurrent Protection	Equipment
Power Consumption (W)	1.5 or less
Flow Rate	Zero point: 4 mA (forward flow display mode, within reverse flow to low flow cutoff), 12 mA (forward and reverse flow display mode, within low flow cutoff)
Pressure	0kPa：4mA, 1MPa：20mA
