| Protection Class | IP67, IP68, IP69K |
| Type of Product | SA1Q type CMOS laser sensor with built-in amplifier |
| Model No | SA1Q-110V |
| Output Type | Analog output |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IP67, IP68, IP69K |
Type of Product |
SA1Q type CMOS laser sensor with built-in amplifier |
Model No |
SA1Q-110V |
Output Type |
Analog output |
Country of Origin |
Japan |
Monotaro ID |
48020028 |
Case Material |
SUS316L |
Included Components |
Quick start guide, mounting screws (M3 x 30), safety label |
Output |
0 - 10V |
Indicator Lamp |
Output: Amber, Display: Stability level: Green, Operation mode selection: Amber 7-segment (4 digits): Red |
Detection Distance (mm) |
35 - 110 |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Mass (g) |
About 80 |
Ambient Illumination to Use (Lx) |
Less than 5000 (at 300mm), 2000 or less (at 500-600mm) |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
Dc12V: -10 To 50°C (But Do Not Freeze), Dc24V: -10 To 45°C (But Do Not Freeze), Dc30V: -10 To 40°C (But Do Not Freeze) |
Storage Temperature Range |
-10 To 50°C (No Icing) |
Lens Material |
PMMA |
Rated Operating Current |
100mA |
Emitting Element |
Red laser diode 655nm, Class 1 (IEC60825-1) |
Power Consumption (mW) |
0.675 or less |
Electric Shock Protection Class |
Power reverse connection protection circuit |
