| Protection Class | IP65(IEC60529) |
| Type of Product | DPRI type proximity switch |
| Model No | DPRI-01-5M |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IP65(IEC60529) |
Type of Product |
DPRI type proximity switch |
Model No |
DPRI-01-5M |
Country of Origin |
Japan |
Monotaro ID |
80689536 |
Operation Mode |
Built-in permanent magnet and reed switch |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Cable Length (m) |
5 |
Mass (g) |
About 40 |
Response Frequency (Hz) |
300 or less (bounce time 0.4 ms or less) |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-10 To 50°C (No Icing) |
Operating Ambient Humidity (% RH) |
35 To 85 (With No Condensation) |
Operating distance (mm) |
5 |
Shock Resistance (m/s²) |
200 or less |
Mechanical Durability |
100 million times or more |
Rated Operating Voltage (V) |
(Output) AC: max100, DC: max100 |
Switch Capacity |
(Output) AC: 10VA, DC: 10W |
Lead Wire |
Cab tire cord, outer diameter Φ4.6, length 1m |
Distance Setting |
0 - 4 |
Standard Detector (mm) |
30 x 20 x 1t, electromagnetic soft iron plate |
Rated Operating Current (A) |
(Output) AC: max 0.25, DC: max 0.25 |
Electrical Durability |
Contact resistance 1.5Ω or less after 20 million operations (10V/100mA resistive load) |
Contact Configuration |
1A |
Contact Resistance |
0.35 Ω (including 1m cable) |
