| Protection Class | IEC standard IP66 |
| Cable Length | 2 m |
| Type of Product | Proximity Sensor |
| Model No | E2K-L13MC1 2M |
Protection Class |
IEC standard IP66 |
Cable Length |
2 m |
Type of Product |
Proximity Sensor |
Model No |
E2K-L13MC1 2M |
Weight |
Approx. 70 g (Packed) |
Country of Origin |
JAPAN |
Detection Method |
Capacitive Method |
Monotaro ID |
39047391 |
Operation Mode |
NO |
Switching Capacity |
100 mA or Less |
Case Material |
Heat Resistant ABS |
Ambient Humidity |
During Use & Storage: 25 to 85 each (No Condensation) |
Included Components |
2 Binding Bands, 4 Non-slip Tubes |
Influence of Voltage |
± 0.5mm of detection level at rated power supply voltage within the range of rated power supply voltage ± 10% |
Connection Type |
Cord drawer type |
Insulation Resistance |
Between live parts and case: 50 MΩ or more (at 500 VDC) |
Power Supply Voltage |
DC12 ~ 24 V Ripple 10% or less |
Vibration Resistance |
10-55 Hz, multiple width 1.5 mm, X, Y, Z directions 2h |
Current Consumption |
12 mA or less |
Influence of Temperature |
Detection level at + 23 ° C within the temperature range of 0 to + 55 ° C ± 4mm (in pure water and 20% salt water) (however, ± 6mm in pure water with a pipe diameter of Φ8) |
Cable Material |
NBR |
Suitable For |
(Applicable pipe) Material: Non-metal, Outer diameter: Φ8-11mm, Wall thickness: 1mm or less |
Repeatability |
± 200 μm or less |
Cover Material |
Heat Resistant ABS |
Residual voltage (V) |
1 V or Less (Load Current: 100 mA, Cord Length: 2 m) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Import Country |
Direct Import from Japan |
