| Protection Class | IEC standard IP67 |
| Cable Length | 1 m |
| Type of Product | Proximity Sensor |
| Model No | E2S-Q26 1M |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Protection Class |
IEC standard IP67 |
Cable Length |
1 m |
Type of Product |
Proximity Sensor |
Model No |
E2S-Q26 1M |
Country of Origin |
CHINA |
Detection Distance |
2.5mm±15% |
Head Shape |
Square |
Monotaro ID |
39047653 |
Switching Capacity |
PNP open collector output 50 mA or Less (30 VDC or less) |
Case Material |
Polyarylate |
Protection Circuit |
Power Supply Reverse Connection Protection, Surge Absorption |
Ambient Humidity |
Operating: 35 to 90, Storage: 35 to 95% RH (No Condensation) |
Included Components |
Mounting Bracket |
Influence of Voltage |
± 2.5% or less of sensing distance at rated power voltage within the range of rated power voltage ± 10% |
Standard sensing Object |
Iron: 15 × 15 × 1 mm |
Connection Type |
Cord drawer type |
Insulation Resistance |
50 MΩ or more (at 500 VDC) between live parts and case |
Setting Distance (mm) |
0～1.9 mm |
Power Supply Voltage |
DC12 ~ 24 V Ripple (pp) 10% or less |
Vibration Resistance |
10~55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Output |
DC 3-Wire PNP |
Operating Voltage Range |
DC10～30 V |
Current Consumption |
13 mA or less (24 VDC, no load) |
Response Frequency |
1k or more |
Residual voltage (V) |
1 V or Less (Load Current 50 mA and Cord Length 1 m) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
