| Protection Class | IEC Standard IP67 |
| Cable Length | 5 |
| Type of Product | Proximity Sensor |
| Model No | E2E-X1R5C18 5M |
Protection Class |
IEC Standard IP67 |
Cable Length |
5 |
Type of Product |
Proximity Sensor |
Model No |
E2E-X1R5C18 5M |
Size |
M8 |
Country of Origin |
Japan |
Type |
Cylindrical Type (With Screw), Short Distance Type |
Detection Distance |
1.5 mm ±10% |
Head Shape |
Screw |
Monotaro ID |
65068195 |
Shield Shape |
Shield type |
Case Material |
Stainless Steel (SUS303) |
Included Components |
Instruction manual, tightening nut, washer with teeth |
Connection Type |
Cord Drawer Type |
Cord |
Standard PVC Code |
Output |
DC 3-Wire |
Standard Sensing Object (mm) |
Iron 8 × 8 × 1 |
Detection Distance (mm) |
1.5±10% |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Body Size |
Standard |
Cable Length (m) |
5 |
Current Consumption (mA) |
16 or Less |
Oscillation Frequency |
Classification) Standard Frequency |
Import Country |
Direct Import from Japan |
Power Supply Voltage (V) |
DC 10-30 (Including 10% Ripple (Pp)) |
