| Protection Class | IEC standard IP67 |
| Type of Product | Chip Prevention Type Proximity Sensor |
| Model No | E2EZ-X2D1-M1GJ-0.3M |
| Country of Origin | China |
Protection Class |
IEC standard IP67 |
Type of Product |
Chip Prevention Type Proximity Sensor |
Model No |
E2EZ-X2D1-M1GJ-0.3M |
Country of Origin |
China |
Type |
Built-in amplifier |
Detection Distance |
2±10% |
Head Shape |
Screw |
Monotaro ID |
46432574 |
Shield Shape |
Shield |
Case Material |
Brass Nickel plating |
Protection Circuit |
Load short-circuit protection, surge absorption |
Included Components |
Instruction manual |
Connection Type |
Connector relay type (M12) |
Setting Distance (mm) |
0 to 1.6 |
Power Supply Voltage |
DC 12 to 24 V Ripple (pp) 10% or less |
Standard Sensing Object (mm) |
Iron 12 x 12 x 1 |
Detection Distance (mm) |
2±10% |
Material |
Clamping nut iron: zinc plated |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Cable Length (m) |
0.3 |
Mass (g) |
Approx. 40 (packed) |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
During operation and storage: 0 to 50 (but do not allow freezing or condensation) |
Insulation Resistance (MOhm) |
Between live parts and case: 50 or more (at 500 V DC) |
Power Supply Voltage (V) |
DC12-24 Ripple (pp) 10% or less |
Locator Material |
Possible: Magnetic metal (non-magnetic metal reduces the detection distance.) |
