Mitsuboshi Nomex E Type Chan Coupling Overall Length 83 mm, Max Torque 88.3 Nm, 8000 RPM, Nor-Mex E82
Direct Import From Japan
Mitsuboshi Nomex E Type Chan Coupling Overall Length 83 mm, Max Torque 88.3 Nm, 8000 RPM, Nor-Mex E82
Mitsuboshi Nomex E Type Chan Coupling Overall Length 83 mm, Max Torque 88.3 Nm, 8000 RPM, Nor-Mex E82

Mitsuboshi Nomex E Type Chan Coupling Overall Length 83 mm, Max Torque 88.3 Nm, 8000 RPM, Nor-Mex E82

Visit the Mitsuboshi Store
power brand
EMI starts at ₹1677/month. No Cost EMI available.
Available offers
Flat ₹200 off on Order above ₹6,000 | Valid for NEW Business Users

View

Flat ₹100 off on Order above ₹4000 | Valid for NEW Business Users

View

Flat ₹500 off on Order above ₹15000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Features
Series Nomex
Size -
Material Aluminum Alloy
Model No Nor-Mex E82
warranty Warranty as per brand
original products 100% Original Products
secure payments Secure payments
buyer protection 100% Buyer protection
top brands Top Brands

Series

Nomex

Size

-

Material

Aluminum Alloy

Model No

Nor-Mex E82

Type of Product

Chan Coupling

Coupling Type

E Type

Country of Origin

Japan

Other Dimensions

lE: 40 mm

Maximum Rotation Speed

8000 RPM

Overall Length (mm)

83

Flywheel

Parts (11): 0.023 GD² Nm² (kg.m²)

Monotaro ID

37185136

Dimension M2 (mm)

24

Dimension d4 (mm)

82

Dimension S1 (mm)

3±1

Outer Diameter (Φmm)

82

Regular Torque

49 Nm

Shaft Hole Diameter d1 (Φmm)

10~32

Mass (Kg)

Parts (11): 0.87 Overall: 1.76

Maximum Torque (Nm)

88.3

No. of Teeth

4

Shaft hole diameter d2 (Φmm)

10~32

Name of Manufacturer/Packer/Importer

Mitsuboshi belting Ltd
