| Series | Nomex |
| Size | 112-158 |
| Material | Aluminum Alloy |
| Model No | Nor-Mex LE112-158 |
Series |
Nomex |
Size |
112-158 |
Material |
Aluminum Alloy |
Model No |
Nor-Mex LE112-158 |
Type of Product |
Chan Coupling |
Coupling Type |
LE Type |
Country of Origin |
Japan |
Other Dimensions |
D2: 60 mm, D5: 112 mm, lE: 60 mm |
Maximum Rotation Speed |
6000 RPM |
Overall Length (mm) |
85.5 |
Flywheel |
Parts (11): 0.101 Parts (17): 0.196 GD² Nm² (kg.m²) |
Monotaro ID |
37185443 |
Dimension M2 (mm) |
38 |
Dimension d4 (mm) |
142 |
Dimension S1 (mm) |
3.5±1 |
Regular Torque |
164 Nm |
Shaft Hole Diameter d1 (Φmm) |
14～48 |
Mass (Kg) |
Parts (17): 1.46 Overall: 3.81 |
Maximum Torque (Nm) |
294 |
Dimension L1 |
22 mm |
Dimension L2 |
10 mm |
Number of Holes |
6 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
