Ships within 25 days
View
View
View
View
| Series | Nomex |
| Size | - |
| Material | Aluminum Alloy |
| Model No | Nor-Mex E330 |
Series |
Nomex |
Size |
- |
Material |
Aluminum Alloy |
Model No |
Nor-Mex E330 |
Type of Product |
Chan Coupling |
Coupling Type |
E Type |
Country of Origin |
Japan |
Other Dimensions |
lE: 160 mm |
Maximum Rotation Speed |
2000 RPM |
Overall Length (mm) |
328 |
Flywheel |
Parts (11): 24.431 GD² Nm² (kg.m²) |
Monotaro ID |
37185242 |
Dimension M2 (mm) |
104 |
Dimension d4 (mm) |
330 |
Dimension S1 (mm) |
8±2.5 |
Outer Diameter (Φmm) |
330 |
Regular Torque |
7080 Nm |
Shaft Hole Diameter d1 (Φmm) |
90～150 |
Mass (Kg) |
Parts (11): 60.1 Overall: 121.3 |
Maximum Torque (Nm) |
12700 |
No. of Teeth |
10 |
Shaft hole diameter d2 (Φmm) |
90～150 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
